AI3048IT
-
caractéristiques
- Rapid preheating Yes
- Bridge Function No data in PDM for HQF
- Bridge power 3,7/5,5
- ChildLock Yes
- Direct Touch Yes
- Front left heating zone dimension (cm) 22x19
- Left front zone energy consumption FL 188.9 Wh/kg
- Front left heating zone power rating (kW) 2.2/3.5
- Left Front Induction Zone Booster No data in PDM for HQF
- Left front zone type FL Induction
- Rear left heating zone dimension (cm) 22x19
- Left rear zone energy consumption RL 188.9 Wh/kg
- Rear left heating zone power rating (kW) 2.2/3.5
- Left rear induction zone booster No data in PDM for HQF
- Left rear zone type RL Induction
- Minute minder Yes
- Mounting data No data in PDM for HQF
- Number of Booster 4
- Bridge zones 2
- Number of power levels 9
- Overflow detection Yes
- Overheat detection Yes
- Pause function Yes
- Residual heat indicator Yes
- Front right heating zone dimension (cm) 22x19
- Right front zone energy consumption FR 188.9 Wh/kg
- Front right heating zone power rating (kW) 2.2/3.5
- Right front induction zone booster No data in PDM for HQF
- Right front zone type FR Induction
- Rear right heating zone dimension (cm) 22x19
- Right rear zone energy consumption RR 188.9 Wh/kg
- Rear right heating zone power rating (kW) 2.2/3.5
- Right Rear Induction Zone Booster No data in PDM for HQF
- Right rear zone type RR Induction
- Slider control Yes
- Small object detection Yes
- Temperature limiter Yes
- 3 warming levels Yes
- Auto switch off Yes
- Timer Yes
- Hob energy consumption 188.9 Wh/kg
- Control type Slider
-
ÉQUIPEMENT
- Power indicator lamp Yes
-
DONNÉES TECHNIQUES
- Connection cable colour White
- Connection type 3N~230/400 V
- Cut out size - depth 490 mm
- Cut out size - width 560 mm
- Display color Red
- Edge finish Bevelled
- Gross volume 0.0525 m³
- Illuminated edge Yes
- Puissance totale 7.4 kW
- In-furniture depth 54 mm
- Middle induction zone Booster No data in PDM for HQF
- Net depth 516.8 mm
- Net height 60 mm
- Poids net 9.3 kg
- Net width 572.4 mm
- Number of heating elements 4
- Type of plug or cable France
- Position Of Connection Cable Middle - rear
- Connection cable Power cord without plug
- Power cabel length 150 cm
- Power Supply Voltage 230_400V
- Hob type Induction
