Air flow at 1 speed - extractor by EN 61591 372 m3/h |
Air flow at 2 speed - extractor by EN 61591 432 m3/h |
Air flow at 3 speed - extractor by EN 61591 477 m3/h |
Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 477 m3/h |
Air Flow at Minimum Speed in Normal Use 372 m3/h |
Air Flow Rate at Best Efficiency Point - Q BEP 266.3 m3/h |
Air Pressure at Best Efficiency Point P BEP 248 Pa |
Consommation d'énergie annuelle 66.4 kWh |
Consommation d 'énergie annuelle 66.4 kWh |
Average Illumination of the Lighting System on the Cooking Surface - E middle 112 lux |
Container qty 40'HQ 535 |
Control panel on one side/two sides One side |
Dimensions of grease filter 683 x 161 mm |
Display color White |
Distance from light cover to wall 21 cm |
Distance to electric hob 45 cm |
Distance to gas hob 65 cm |
Electric Power Input at Best Efficiency Point - W BEP 118 W |
Energy Efficiency Index - EEI hood 78.3 |
Efficacité de la dynamique des fluides 15.5 |
Efficacité de la dynamique des fluides D |
Grease Filtering Efficiency - GFE hood 79 % |
Étiquette d’efficacité de filtration des graisses C |
Gross volume 0.1329 m³ |
Internal/external motor Internal |
Main lighting colour temperature [K] 6500 |
Éclairage 13.5 lux/W |
Étiquette d’efficacité lumineuse D |
Éclairage D |
Maximum Possible Air Flow 477 m3/h |
Moteur 150 W |
Moteur E series |
Net depth 31 cm |
Net height max 25.6 cm |
Net height min 25.6 cm |
Poids net 9.7 kg |
Net width 85 cm |
Niveau sonore 59 dB |
Niveau sonore 61 dB |
Niveau sonore 63 dB |
Nominal Power of the Lighting System - W L 8.3 W |
Number of motor units 1 |
Number units of main lighting 1 |
Diamètre de l'échappement d'air 15 cm |
Type of plug or cable Euro plug |
Power Consumption in Standby Mode - Ps 0.42 W |
Power cabel length 120 cm |
Power rating 158 W |
Power Supply Voltage 230V |
Power unit of main lighting 8 W |
Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 63 dB |
Sound Power Emission at Minimum Speed Available in Normal Use 59 dB |
Niveau sonore 63 dB |
Time Increase Factor - f 1.4 |
Type of main lighting LED strip |
